DESCRIPTION

Basic Info

Model NO.	XFDII-8
Type	Mechanical Agitating Tank
Motor Power	250W
Mining Object	Ore
Motor Type	AC Motor
Impeller Type	Single Impeller
Certification	CE, ISO
Automation	Automatic
Warranty	1 Year
Customized	Non-Customized
Condition	New
After-sales Service	1 Year
OEM	Yes
Shipping Way	by Sea, DHL, FedEx, UPS, TNT, EMS
Pay Terms	Tt, Paypal, Credit Card, Western Union
Product Name	Laboratory Flotation Cell Machine
Transport Package	Carton
Specification	650*400*900mm
Trademark	WKD
Origin	China
HS Code	8474100000
Production Capacity	1000sets/Month

Packaging & Delivery

Package size per unit product 65.00cm * 40.00cm * 90.00cm Gross weight per unit product 80.000kg

Product Description

Introduction

The XFD series single cell lab flotation machine have three types: XFDI, XFDII, XFDIII. XFDI small flotation cell: the ordinary simple type, the impeller rotary speed can not be adjustable, and without LED displayscreen,applied in laboratory flotation of a small amount of sample ore in such areas as geology,metallurgy,building material and chemical industry.

Technical parameters	Models
	WXFD0.5	WXFD0.75	WXFD1.0	WXFD1.5	WXFD3.0	WXFD8
Capacity(L)	0.5	0.75	1	1.5	3	8
Rotary speed of impeller(r/min)	2590/2340		2100/1900	1910/1750	1890/1708	1400
Impeller diameter (mm)	45		55	60	70	100
Rotary speed of scraper(r/min)	15/30			7.9/19.1
Size of feeding(mm)	≤0.2
Motor power(w)	90					250
Overall size(mm)	380*310*680		440*310*760		440*310*820	650*400*900
Weight(kg)	26		32		50	78

XFDII small flotation cell: it is the updated version of XFD I, the impeller rotary speed can be adjustable as your needs, butwith LED display screen, without heater device, can not control temperature of the minerals.Applied in stirring,scrubbing,separation and selection of small amounts of sample ore om labs of research institutes and mining bodies involving geology,metallurgy,building materials and chemical industries.

Item No.	WXFDII0.5	WXFDII0.75	WXFDII1.0	WXFDII1.5	WXFDII3.0	WXFDII8
Groove Capacity (L)	0.5	0.75	1.0	1.5	3.0	8.0
Rotary Speed of Impeller (r/min)	0-2800					0-1400
Impeller Diameter (mm)	φ45		φ55	φ60	φ70	φ100
Rotary Speed of Scaper (r/min)	30 20
Feeding Size (mm)	0.04-0.25
Voltage (V)	220V
Dimension (mm)	440*320*740			440*320*830		650*400*900
Weight (kg)	30			32	38	80

XFDIII small flotation cell: It is the highest grade type. It uses inverter technology, variable speed impeller, digital display,and also change from the outside air to intake inflated with precise adjusted, clear and stable display.According to user needs, it can be equipped with a heater, temperature control device to control, display tank mine fluidtemperature at any time.XFDIII small flotation cell can be equipped with additional water level automatically adjusts automatically administration and other devices, can achieve a higher level of automation. Gas of pump tank supply to the rotor agitation, and mix with ore fluid, the stator is cut to produce tiny bubbles mineralization Rotor speed is stepless and can be adjusted by inverter.Fixed flotation tank fasten by hand wheel drive screw clamp.Shaving foam body, its trajectory is a circular motion.Applied in geology,metallurgy,building materials,chemical and other industrial laboratory flotation ore with a small amount.

Item No.	WXFDIII0.5	WXFDIII0.75	WXFDIII1.0	WXFDIII1.5	WXFDIII3.0	WXFDIII8
Groove Capacity (L)	0.5	0.75	1.0	1.5	3.0	8
Rotary Speed of Impeller (r/min)	0-2800					1400
Impeller Diameter (mm)	φ45		φ55	φ60	φ70	φ100
Rotary Speed of Scraper (r/min)	15-30
Feeding Size (mm)	0.25
Temperature adjustable range (ºC)	50-95
Motor (w)	120					250
Voltage (V)	220
Dimension (mm)	440*320*740			440*320*830		650*400*900
Weight (kg)	30			32	38	80

FeaturesWorking Principle

Before operation, check whether the main shaft turns clockwise. If not, then change phase sequence of the power source to make the motor turns clockwise before operation. Mix mineral samples and water and then pour them into the cell. Start up the motor to drive the main shaft for rotation. The impeller will agitate in the cell. Then open the valve for air inflation and add chemical agent to form foams. Turn on switch of the scraper motor (8) for rotation of the scraper to scrape foams out of the cell. A box is set on the working table to receive foams. Minerals needed can be obtained after processing of the foams.

Advantage

* Small size, light weight, low noise.

* Simple structure, easy maintenace.

* The motor speed can be controlled by the frequency.

* Stepless speed regulation of impeller, digital display, accurate adjustment.With Heater, can heat and control the temperature of ore liquid.
